MAX° VCPLD
At the same time, low cost, low power consumption and on-chip characteristics are realized. MAX °V CPLD is the most valuable device on the market.MAX V devices adopt a unique non-volatile architecture, providing reliable new features, and the total power consumption is reduced by up to 50 per cent compared with competitive CPLD.
SERIES OF VARIANTS
ALL MAX °V VARIANTS
Understand in detail the comparison of
all the equipment branches and the current situation
ADVANTAGE
OPTIMAL CPLD VALUE
When you use MAX v devices, because the MAX v architecture integrates previous external features, such as flash memory, RAM, oscillators, phase-locked loops, and so on, you will achieve lower total system costs. MAXVCPLD provides a large number of 1≤0 and logic in unit space.The devices also use low-cost green packaging technology, which is only 20 millimeters in size.
REDUCE TOTAL POWER CONSUMPTION
Compared with other CPLD with the same density on the market, MAX V CPLD provides you with reliable new features while reducing total power consumption by up to 50 per cent.
●The battery life is prolonged and the static power consumption is as low as 45 uW.
●Only the circuit power supply voltage (Ncc- core) is needed, and the cost of material table (BOM) is also reduced.
Using a mature low-cost wafer manufacturing process, MAXV CPLD takes advantage of a mature architecture while achieving reliable functions, including:
●System programming (ISP) helps you program your device while it is working, so you can update
it on site without afecting the overall operation of the system User flash memory,
●that is, embedded flash memory which provides non-voltile memory storage for important system information.
●Digital PLL (DPLL), which supports flexible design that requires frequency doubling or phase shift.
FREE DESIGN SOFTWARE THAT IS EASY TO USE
Free Quartus °Prime Lite Edition software supports MAXV CPLD. With Quartus Prime software, you will gain productivity enhancements that speed up simulation, circuit board startup, and timing convergence. The software also comes with a system-level integration tool called Qsys that improves circuit performance and allows you to design at a higher level of abstraction.
CHARACTERISTIC
MAX °V devices are suitable for general use, power consumption and space constrained designsin many segments of the market.
DESIGN TOOL
The resources provided here help you start design with MAX °V CPLD devices.
TRAINING
Learn about our training courses, including online training and teacher directed courses.
DOWNL OAD CABLE
Learn more about the selection of download cables used in MAXVCPLD programming
QUARTUS "PRIME SOFTWARE
How Quartus Prime software supports MAX °V CPLD design.
THE MAX "V POWERPL AY EARLY POWER ESTIMATE
estimates the power consumption of your MAX °VCPLD design.
LEARN TO USE QUARTUS PRIME SOFTWARE
Zuo Shi became the designer of the partial program wet series. diting? Touching Qustuse Prime software for the first time?Watch these online demos at your own time and learn how to become an editable logic designer in about an hour
IP WEBSITE
Select of-the-shelf iP core functionality from ys and our partners IP cores are optimized for our devices, with minimal design and test time,and can be evaluated in hardware and simulation prior to licensingmos at your own time and learn how to become an editable logic designer in about an hour
DESIGN EXAMPLE
Download a design example of common features that are actually performed in CPLD.
